Caline CP 05 Guitar Effect Pedals Power Supply Ten Isolated Output (9V 12V 18V) voltage protection with Blue LED Light-in Guitar Parts & Accessories from Sports & Entertainment

Scroll to product details, material & care and sizing

$ 28.00

Add to cart Add to wishlist

Term:
calin, guitar pedal power supply, battery led string, Wholesale caline distortion, Wholesale ckk, Wholesale calin, Wholesale 2 wing pendant, Wholesale battery led string, Wholesale guitar power supply, Wholesale pure sky, Wholesale caline power supply, Wholesale effect pedal,

Caline CP-05 Guitar Effect Pedals Power Supply Ten Isolated Output (9V 12V 18V) voltage protection with Blue LED Light Details & Specification :

Item Specifications
Model Number Caline CP-05
Type Effects
Material Aluminum alloy
Power adapter AC 100-240V, 50/60Hz
Input: DC 18V
Power for 9V, 12V or 18V Pedal
Power supply size 14.8 x 5 x 3.2cm
package weight 388g

A

Caline CP-05 Guitar Effect Pedals Power Supply Ten Isolated Output (8 Way DC 9V & 1 Way DC 12V & 1 Way 18V) voltage protection



Ten isolated output.
Isolated short circuit / overcurrent protection.
Powers for 9V, 12V or 18V Pedal.
Bright blue LED for Pedal Board lighting & short circuit indicating.
Includes cables.
PART NAMES AND FUNCTIONS
1. Switch for LED lights: Tur1n the switch towards those LED lights,normally all lights would go on after the power is connected. If you don't want all LED lights, please turn the switch back.The front panel of this unit has 10 high-brightness LED lights working as indicators, as well as lighting for pedal board.
2. DC 18V INPUT: Please plug in the output of power adapter here,and do not use adapter from elsewhere
3. OUTPUT 1-7: All DC 9v power output with the maxinmum volume of 100mA,are suitable for ordinary analog effectors. Under the circumstances of all LED lights on, instantaneous overcurrent in certain output would lead to the corresponding LED light's flash and the currents of this channellimit to 100mA. That is to say, output 1-7 might not be able to work properly if the connected digital effectors are of larger power consumption, then you need to use output 8.
4. OUTPUT 8: A lso DC 9V Power output with maximum volume of 500mA,is suitable for digital effectors and DC 9V low-power digital guitar amplifiers. When instantaneous overcurrent occuss in this channel, the corresponding LED light would be flashing and the currents limit to 500mA.
5. DC12 OUTPUT: The maximum output current is 100mA, when instantaneous overcurrent occurs in this channel, the corresponding LED light would be flashing and the currents limit to 100mA.
6. DC18 OUTPUT: The maximum output current is 100mA. when instantaneous overcurrent occurs in this channel, the corresponding LED light would be flashing and the currents limit to 100mA.



1

Specifications:

Material: Aluminum alloy
Power adapter: AC 100-240V, 50/60Hz
Input: DC 18V
Output: 7 way 9V 100mA
1 way 9V 500mA
1 way 12V 100mA
1 way 18V 100mA
Power for: 9V, 12V or 18V Pedal
Power supply size: 14.8 x 5 x 3.2cm



Package List:

1 x Power Supply
1 x Power Adapter
10 x Power Cables
2 x Polarity Reversal Cables
1 x User Manual
